Re turned
String: CHCFG <c>,<config>
CHRES Set chan nel deci mal point reso lu tion
CHAN NEL
Syn tax: CHRES <c>,<val>
c: 1 or 2
val: 1 to 3
Re marks: Set the num ber of dec i mal places dis played for the spec i fied chan nel. For
ex am ple, spec i fy ing CHRES 1, 1 would yield a dis play of 1.5 dBm;
CHRES 1, 2 would yield 1.47 dBm; CHRES 1, 3 would yield 1.468 dBm.
If the num ber to be dis played is too large for the num ber of dec i mal
places se lected, the dec i mal places dis played will be re duced so that the
dis play value can be shown.
Query: CHRES? <c>
Re turned
String: CHRES <c>,<val>
CHU NIT Set Chan nel units
CHAN NEL
Syn tax: CHU NIT <c>, <units>
c: 1 or 2
units: W (Watts)
DBM (dB)
DBUV (dB
mV)
DBMV (dBmV)
Re marks: DBM 0dB is equal to 1mW read out mode
W = Watts read out mode
V = Volts read out mode. This se lec tion is au to mat i cally made when the
chan nel in put con fig u ra tion is set to Ex ter nal volts (EXT V).
DBUV = dB
mV, 0dB is equal to 1 mV in read out mode.
Query: CHUNIT? <c>
Re turned
String: CHUNIT <c>,<units>
When the chan nel in put con fig u ra tion is set to Ex ter nal volts (EXT V),
the re turned units are al ways volts, ir re spec tive of what units have been
set.
CONT Con tinue
GPIB SETUP
ML2400A OM 6-29
GPIB OPERATION ML24XXA NATIVE COMMANDS
