state: ON or OFF
Re marks: When us ing GPIB mea sure ment, speed can be in creased by not up dat ing
the dis play. This com mand turns off the dis play and writes
RE MOTE across the screen. If the LO CAL soft key is pressed, the sys -
tem re verts to DISP ON. The re stric tions of this mode are:
1. Min max val ues read via the GPIB are not up dated.
2. Rel a tive op er a tion is ig nored so that the nor mal value is given.
3. DISP will not op er ate when sent via RS232.
4. In CDMA read out mode the DISP OFF com mand will not im prove the
read ings per sec ond.
Query: DISP?
Re turned
String: DISP <state>
DPEAK Peak me ter dis play
DIS PLAY
Syn tax: DPEAK <mode>
mode: A
B
A&B
OFF
Re marks: Turns the peak me ter dis play on or off for each chan nel.
A = Sen sor A only
B = Sen sor B only
A&B = Sen sors A and B dis played at the same time
OFF = Turns the peak me ter dis play off.
The peak me ter dis play range cov ers 12 dB. When above the dis played
maxi mum or be low the dis played mini mum, the range is switched by 10
dB in the ap pro pri ate di rec tion.
Note that in the event that the chan nel is dis play ing an al ter na tive mea -
sure ment (e.g., ex ter nal volts from the rear panel BNC) the peak me ter
con tin ues to rep re sent the Sen sor A and/or B data. This is very use ful
for mon i tor ing an ex ter nal volt age on the me ter, while peak ing up a re -
sponse be ing mon i tored by a sen sor (e.g., RF out put).
Query: DPEAK?
Re turned
String: DPEAK <mode>
6-34 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
