mode NORM
MIN MAX
MIN
MAX
AVG
Re marks: Changes the type of graph dis played:
NORM: Pro files the sen sor read ings vs. time from the trig gered point.
MINMAX: Plots both the MIN and MAX val ues for each point on the
graph. If con nect points ( GRCP ) is ON, a ver ti cal bar is drawn be tween
the min and max points.
MIN: Same as NORM, but each point is the min i mum value that point
has achieved.
MAX: Same as NORM, but each point is the max i mum value that point
has achieved.
AVG: This po si tion plot ted on the chart for an x-axis time slot is the av -
er age of all the read ings dur ing that x-axis time slot pe riod, and is only
avail able in Power vs. Time mode.
Query: GRPIX?
Re turned
String: GRPIX <mode> (Mode can be AVG in Power vs. Time mode.)
GRPRD Pro file data col lec tion pe riod
PRO FILE SETUP
Syn tax: GRPRD <val>[units]
val: 100 ns to 7 sec onds
Re marks: Sets the time the sys tem will col lect data for and scale into the pro file
graph af ter a trig ger event.
Ex am ple: GRPRD 20US sets the data col lec tion pe riod to 20 mi cro sec onds.
Query: GRPRD?
Re turned
String: GRPRD <val>
GRPTP Graph Pretrigger Per cent age
PRO FILE SETUP
Syn tax: GRPTP <val>[units]
val: 0 to 100
units: PCT
Re marks: Sets the pre trig ger per cent age of the pro file screen. The per cent age of
the data col lec tion pe riod that shows pretrigger infomation if the dis play
trig ger de lay is 1/PRF.
6-44 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
