–23 to 94 dBmV
37 to 154 dB
mV
Re marks: Sets up the start value for the an a log out scale of the dis play.
Query: OBDST? <port>
Re turned
String: OBDST <port>,<units>,<val>
OBMD BNC out put mode se lect
BNC
Syn tax: OBMD <port>,<mode>
port: 1 or 2
mode: 'OFF' (out put set to ground) port 1 or 2
'AOUT' (an a log scaled out put) port 1 or 2
'PASS/FAIL' (pass/fail) port 1 or 2
'SIGA' (sig nal out put sen sor A) port 1 only
‘LVLA1’ Sig nal chan nel range 1 am pli fier out put for sen sor A
‘LVLA2’ Sig nal chan nel range 2 am pli fier out put for sen sor A
‘LVLB1’ Sig nal chan nel range 1 am pli fier out put for sen sor B
‘LVLB2’ Sig nal chan nel range 2 am pli fier out put for sen sor B
'ACMOD' (AC mod out put) port 1 only
'RFB' (RF blank ing while ze ro ing) port 2 only
'SIGB' (sig nal out put sen sor B) port 2 only
Re marks: Changes the type of out put se lected for the BNC out puts.
Query: OBMD? <port>
Re turned
String: OBMD <port>,<mode>
OBPL BNC pass/fail pass level
BNC
Syn tax: OBPL <port>,<level>
port: 1 or 2
level: HIGH ( TTL high is PASS)
LOW ( TTL low is PASS)
Re marks: Se lects the PASS level for the Pass/fail type of out put.
Query: OBPL? <port>
Re turned
String: OBPL <port>,<level>
6-60 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
