OFFCLR Clear an off set ta ble SEN SOR
Syn tax: OFFCLR <val>
val: 1 to 5
Re marks: Sets all the val ues in the ta ble speci fied to 0 dB and 0.00 Hz.
OFF FIX Off set fixed value
SEN SOR
Syn tax: OFF FIX <s>,<val>[units]
s: A or B
val: –99.999 to +99.999
units: dB
Re marks: The value added to the sen sor if the off set type is set to FIXED.
Ex am ple: To set the fixed offset for sensor A to -47 dBm:
OFFFIX A,-47DB
Query: OFFFIX? <s>
Re turned
String: OFFFIX <s>,<val>
OFFTBL Spec ify the ta ble used to ap ply off sets to the sen sor
SEN SOR
Syn tax: OFFTBL <s>, <val>
s: A or B
val: 1 to 5
Re marks: If the Off set Type is set to TA BLE, use this com mand to spec ify which of
the five off set ta bles to ap ply to the sen sor.
The ta bles are a set of frequency- against- dB off sets. The off set value
used from the ta ble de pends on the set ting of the fre quency cor rec tion
source. If the source is FRE QUENCY, the en tered fre quency is used to
cal cu late the off set from the ta ble. If the fre quency cor rec tion source is
V/GHz, the fre quency value cal cu lated from the sup plied ramp in put is
used to cal cu late the off set from the ta ble.
If the fre quency does not match any fre quency in the ta ble, in ter po la -
tion is used to cal cu late the cor rect off set.
6-62 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
