TR0 Trig ger hold mode GPIB TRIG GER
Syn tax: TR0
Re marks: Sets both chan nels to trig ger hold mode. It does not trig ger un til it re -
ceives a TR1 or TR2 or GET (group ex ecu tive trig ger), *TRG or TR3
com mand. If it re ceives a TR3 com mand it re verts back to the trig ger
mode it was in be fore the TR0 com mand was sent. If the REM line is
low, this com mand has no ef fect.
Re lated
Com mands: TR1, TR2, TR3, *TRG, Group Exe cute Trig ger (GET), GT0, GT1, GT2
TR1 Trig ger im me di ate
GPIB TRIG GER
Syn tax: TR1 <c>
c: 1 or 2
Re marks: Trig gers a sin gle read ing which is added to the in ter nal dig i tal fil ter and
the up dated fil ter power level is re turned on the GPIB. The re turned
read ing dif fers de pend ing on the op er a tion mode:
Read out: 'O' com mand re sponse
Pwr vs. Time: 'O' com mand re sponse
Pro file: 'OGBD' com mand re sponse (bi nary graph data for ex am ple)
Source Sweep: 'OGBD' com mand re sponse (bi nary graph data for ex am ple)
Af ter a TR1 com mand the in stru ment re turns to ei ther TR0 (trig ger
hold) or TR3 (trig ger free run) mode de pend ing on what it was pre vi -
ously set to.
Re lated
Com mands: TR0, TR2, TR3, *TRG, Group Exe cute Trig ger (GET), GT0, GT1, GT2
TR2 Trig ger with a set tling de lay
GPIB TRIG GER
Syn tax: TR2 <c>
c: 1 or 2
Re marks: Trig gers a fully ranged and set tled read ing which is re turned on the
GPIB Bus. If av er ag ing is set to ON, the av er age buffer will be cleared
and filled be fore the re sult is re turned. The re turned read ing dif fers de -
pend ing on the op er a tion mode:
Read out: 'O' com mand re sponse
Pwr vs. Time: 'O' com mand re sponse
ML2400A OM 6-79
GPIB OPERATION ML24XXA NATIVE COMMANDS
