Pro file: 'OGBD' com mand re sponse (bi nary graph data for ex am ple)
Source Sweep: 'OGBD' com mand re sponse (bi nary graph data for ex am ple)
NOTE
TR2 in Pro file and Source Sweep mode is not sup ported
and will re vert to a TR1 type mea sure ment.
If the chan nel is set to Ex ter nal Volts, TR2 is not sup -
ported (as there is no av er ag ing and set tling) and will re -
vert to a TR1 type mea sure ment.
Af ter a TR2 com mand the in stru ment re turns to ei ther TR0 (trig ger
hold) or TR3 (trig ger free run) mode de pend ing on what it was pre vi -
ously set to.
Re lated
Com mands: TR0, TR1, TR3, *TRG, Group Exe cute Trig ger (GET), GT0, GT1, GT2
TR3 Trig ger free run
GPIB TRIG GER
Syn tax: TR3
Re marks: Sets the ML2400A Se ries back into free run mode on both chan nels.
Re lated
Com mands: TR0, TR1, TR2, *TRG, Group Exe cute Trig ger (GET), GT0, GT1, GT2
TRGARM Trig ger arm ing
TRIG GER
Syn tax: TRGARM <c>, <state>
c: 1, 2 or 1&2
state: ON or OFF
Re marks: Sets the read out trig ger arm ing ON or OFF when in READ OUT or
POWER vs. TIME mode.
Se lect chan nel 1, 2 or 1&2. Se lecting 1&2 al lows both chan nels to trig ger
to gether on the same con di tions with out hav ing to set up two sets of
trig ger data.
If set to ON, the sys tem first checks to see if the BNC sweep blank ing in -
put is TRUE be fore it starts to trig ger. If set to OFF, the sys tem uses the
trig ger source (TRSRC) to de cide when to trig ger.
TRGARM will re turn an ex e cu tion er ror if try ing to set trig ger arm ing
ON when a dis play chan nel trig ger source is al ready set to EXTTTL, as
they both use the same BNC in put.
Query: TRGARM? <c>
6-80 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
