Re turned
String: TRGMODE <mode>
TRGSRC Set trig ger source
TRIG GER
Syn tax: TRGSRC <c>,<source>
c: 1, 2 or 1&2
source: INTA (in ter nal sen sor A)
INTB (in ter nal sen sor B)
EXTTTL (ex ter nal BNC TTL trig ger in put)
MAN UAL (man ual push but ton trig ger)
CONT (con tinu ous)
Re marks: This com mand is over rid den by the TR0, TR1 and TR2 com mands when
in READ OUT or POWER vs. TIME mode. If TR3 is sent, the trig ger
source re verts back to the pre vi ously se lected type of trig ger ing.
Se lect chan nel 1, 2 or 1&2. Se lecting 1&2 al lows both chan nels to trig ger
to gether on the same con di tions with out hav ing to set up two sets of
trig ger data.
Query: TRGSRC? <c>
Re turned
String: TRGSRC <c>,<source>
The TRG type com mands re turn the trig ger state of the se lected chan -
nel if the chan nel is ON. This de pends on the set tings of the “link trig -
gers” flag and the cur rent mode of the sen sor on the se lected chan nel. If
the chan nel is OFF, the stored trig ger state of the chan nel is re turned.
TRGTYP Set Trig ger type
TRIG GER
Syn tax: TRGTYP <c>,<type>
c: 1, 2 or 1&2
type: RISE
FALL
Re marks: Sets the con trol type of the trig ger used when the source is set to ei ther
INTA or INTB (in ter nal A or B) in READ OUT or POWER vs. TIME
mode.
Se lect chan nel 1, 2 or 1&2. Se lecting 1&2 al lows both chan nels to trig ger
to gether on the same con di tions with out hav ing to set up two sets of
trig ger data.
Query: TRGTYP? <c>
ML2400A OM 6-83
GPIB OPERATION ML24XXA NATIVE COMMANDS
