The TRG type com mands re turn the trig ger state of the se lected chan -
nel if the chan nel is ON. This de pends on the set tings of the “link trig -
gers” flag and the cur rent mode of the sen sor on the se lected chan nel. If
the chan nel is OFF, the stored trig ger state of the chan nel is re turned.
TRGLVL Set trig ger level
TRIG GER
Syn tax: TRGLVL <c>,<val>
c: 1, 2 or 1&2
val: –30 to +20 dBm
Re marks: If the Trig ger source is set to INTA or INTB (in ter nal A or B) the sys -
tem trig gers on a ris ing or fall ing power level edge. Use this com mand to
set the level the chan nel must rise above or fall be low be fore it trig gers
when in READ OUT or POWER vs. TIME mode.
Se lect chan nel 1, 2 or 1&2. Se lecting 1&2 al lows both chan nels to trig ger
to gether on the same con di tions with out hav ing to set up two sets of
trig ger data.
Query: TRGLVL? <c>
Re turned
String: TRGLVL <c>,<val>
The TRG type com mands re turn the trig ger state of the se lected chan -
nel if the chan nel is ON. This de pends on the set tings of the “link trig -
gers” flag and the cur rent mode of the sen sor on the se lected chan nel. If
the chan nel is OFF, the stored trig ger state of the chan nel is re turned.
TRGMODE Change trig ger mode
TRIGGER
Syn tax: TRGMODE <mode>
mode: IND
COMB
Re marks: Changes the trig ger op er at ing mode be tween IN Di vid ual chan nel trig ger
set ups and COM Bined trig ger set ups. In di vid ual set up is when the trig -
ger con di tions for each chan nel are setup sep a rately. The com bined
setup al lows both chan nels to trig ger to gether on the same con di tions.
If a chan nel is OFF or sen sors used in both chan nel con fig u ra tions do
not in clude a sen sor set to CUS TOM mea sure ment mode, the
COM Bined trig ger mode is not al lowed, and send ing the GPIB com mand
TRGMODE COMB will pro duce an ex e cu tion er ror.
Query: TRGMODE?
