Tools Required: 1 Small Phillips screw driver
1 Large Phillips screw driver
1 Small Phillips torque screw driver 10cNm to 120cNm.
1 Assembly drawing “ML2400/03 SIDE BY SIDE
OPTION”
Assembly Procedure 1. Confirm the correct tools are available and the parts listed above are present.
Refer to diagram on page 2-8 throughout this procedure.
2. On the two sides of the power meter to be joined together, fit the two rear
brackets 49413, C37279, and two front brackets C37275, C37277 using 8
screws 905-68 and 8 washers 900-345. (See max. torque settings page 2-6).
3. Slide the two PM units together and secure using 4 counter sink screws
905-69.
4. Fit the two handles 783-1055 to the front rack brackets using 4 screws
900-795.
5. Locate the two front rack brackets C37276 and 49415 at the front of each of
the PM’s, one on each side with four screws 905-68 and four washers 900-345.
See max, torque setting above.
6. Locate the two rear rack brackets C41449 at the back of each of the PM’s one
on each side with four screws 905-68 and four washers 900-345. (See max.
torque settings page 2-6).
7. Fit the four speed nuts 790-319 to the rack in the correct place to allow
mounting of the two PM’s in the rack.
8. Slide the instruments into the rack and secure with the four decorative
screws (900-821) provided.
INSTALLATION RACK MOUNTING
ML2400A OM 2-7
