ML2400A OM A-3
APPENDIX A SYSTEM SPECIFICATIONS
Limit Lines: Fixed value high and low lim its with audi ble, rear
panel TTL out put, and/or visi ble Pass/Fail alarm in -
di ca tion. Fail ure in di ca tion can be set to latch un til
cleared so that a tran sient fail ure can be eas ily no -
ticed.
Cur sors: Two manu ally ad just able cur sors with power, delta
cur sor power, be tween cur sor power av er age, and
delta time read out dis play.
Delta t
Reso lu tion: 0.5% of dis play pe riod or 100 ns
TRIG GER ING
Trig ger
Sources: In ter nal , Ex ter nal TTL, GPIB, Man ual, Con tinu ous
De lay Range: 0.01 to 1000.00 mil li sec onds
De lay
Reso lu tion: 0.5% of dis play pe riod or 100 ns
In ter nal
Trig ger
Range:
–10.0 to + 20.0 dBm MA2470A Se ries Sen sors.
Selectable to –45 dBm
MA2469A: –60 to +20 dBm, nom i nal bw 1.2 MHz
In ter nal
Trig ger Level
Ac cu racy: 1.0 dB, typi cal
Ex ter nal
Trig ger
Range:
TTL ris ing or fal ling edge trig ger. BNC in put.
Man ual
Trig ger: Front Panel soft key
SYS TEM CON FIGU RA TION
Dis play: LCD Graphic dis play with dual chan nel read out
mode and dual peak me ters. Back light and ad just able
con trast stan dard.
Save/Re call:
Setup
Mem ory: 10 stor age reg is ters plus RE SET de fault set tings
