A NUMBER [GRSWP]
B NUMBER (ML2408A only) [GRSWP]
Sweep av er ag ing number (1 to 512).
RE SET
Sweep av er age re set. If the graph sweep av er ag ing state is ON,
this key re sets the data points and re starts the sweep to sweep
mode.
CUR SOR
[GRSWR]
Be tween cur sor av er ag ing ON or OFF. When ON, a digital
readout of the average power between the two cursors is
displayed in the readout area of the PROFILE dis play.
Off set Al lows an off set, in dB, to be ap plied to sen sor data for the se lected sen sor.
SEN SOR Model ML2408A (dual chan nel) only. Used to se lect the sen sor to
be con fig ured. Tog gles be tween Chan nel A and Chan nel B for all
sub menu func tions.
TYPE
[OFFTYP]
Se lects the type of off set to be ap plied:
Off
No off set ap plied.
Fixed
A fixed dB off set VALUE is ap plied to the sen sor data.
Ta ble
The ta bles are a set of frequency- against- dB off sets. The off set
value used from the ta ble de pends on the set ting of the fre quency
cor rec tion source. If the source is FREQUENCY, the en tered fre -
quency is used to cal cu late the off set from the ta ble. If the fre -
quency cor rec tion source is V/ GHz , the fre quency value
cal cu lated from the sup plied ramp in put is used to cal cu late the
off set from the ta ble.
If the fre quency does not match any fre quency in the ta ble, in ter -
po la tion is used to cal cu late the cor rect off set.
NOTE
If the fre quency is greater than the maxi mum fre quency
in the ta ble, the off set value from the maxi mum ta ble fre -
quency is used. If the fre quency is less than the mini mum
fre quency in the ta ble, the off set from the mini mum ta ble
fre quency is used.
VALUE
[OFFFIX
OFFVAL]
En ter the off set value (dB) when Off set TYPE is set to Fixed.
Valid range is –99.99 to +99.99.
ML2400A OM 4-11
OPERATION SENSOR MENU
NOTE
Use Fixed or Ta ble to
com pen sate for a fixed
at tenu ator on a sen sor
for mea sur ing higher
power lev els. A better
method is to ap ply a
Fixed cal fac tor in the
User ta bles as this is
then taken into ac count
in the Zero/Cal pro -
cess.
