TA BLE
[OFFTBL
OFFTBR
OFFTBU
OFFVAL]
Se lect the off set ta ble number (1-5) when Off set TYPE is set to
Ta ble. When a ta ble is se lected, ad di tional soft keys become
avail able:
EDIT
This will bring up all of the se lected off set ta ble’s en tries, with
their as so ci ated fre quen cies and off sets. Se lect an en try and en ter
the fre quency and off set us ing the key pad.
CLEAR [OFFCLR]
When an off set ta ble is se lected, CLEAR will set all of the ta ble’s
ele ments to zero.
Duty cy cle Ap plies a duty cy cle to the se lected sen sor. An off set will be ap plied based on
the en tered value.
SEN SOR Model ML2408A (dual chan nel) only. Used to se lect the sen sor to
be con fig ured. Tog gles be tween sensor A and sensor B for all sub -
menu func tions.
STATE
[DUTYS]
ON or OFF
DUTY
[DUTYS]
De lete, En ter, or Can cel. An off set will be ap plied based on the
en tered value. For ex am ple, speci fy ing a duty cy cle of 50% will al -
ter the dis played read ings by ap proxi mately +3.01 dB.
Rng Hold
[RGH]
This func tion will toggle the sensor between holding the present operating
range and Auto Rang ing. Auto Rang ing auto mati cally se lects the best range to
take the meas ure ment.
If either sen sor is auto rang ing, this key will force both sen sors to hold their
pres ent op er at ing ranges. If either sen sor is held within an op era tion range,
this key will force both sen sors to Auto Range.
4-12 ML2400A OM
SENSOR MENU OPERATION
NOTE
Rng Hold is not avail able
when Sys tem|Setup|mode
is set to Source Sweep. In
this mode, AUTO rang ing is
used.
