PEAKMETER
[DPEAK]
Turns on the peak me ter dis play for Sen sor A, Sen sor B, or both
Sen sors A and B. The peak me ter dis play will eclipse any trig ger
icons. The peak me ter dis play range cov ers 12 dB. When above
the dis played maxi mum or be low the dis played mini mum, the
range is switched by 10 dB in the ap pro pri ate di rec tion.
The Peakmeter dis play is not avail able when the me ter is op er at -
ing in CDMA Read out mode. If peak mea sure ments are re quired
while in CDMA Read out mode, se lect Chan nel | Setup | CMDA |
PEAK .
FREQ
[FROFF]
Turns FREQuency off set dis play ON or OFF. When ON, a con tin -
u ous in di ca tion of the fre quency (used for Cal Fac tor) is dis played
in small text at the top of the dis play along with any sen sor off set
(if ap plied).
TEXT
[TEXT
TEXTS]
GPIB user TEXT dis play ON or OFF. When ON, a user-defined
text string can be dis played at the top of the dis play area. The
text string can only be de fined over the GPIB.
Sound Con trols sys tem sounds.
KEY
[KEYCK]
Turns the audi ble key click on or off.
EDIT
[ENTERR]
Turns the audi ble edit er ror tone on or off.
LIMIT 1
[FBEEP]
Limit Fail beep on chan nel 1 on or off.
LIMIT 2
[FBEEP]
Limit Fail beep on chan nel 2 on or off.
CUR SOR CURSOR out of screen beep. If a cur sor is moved into an il le gal
space, such as the edge of the screen or the end of valid data, a
warn ing beep is sounded.
ML2400A OM 4-29
OPERATION SYSTEM MENU
NOTE
In the event the chan -
nel is dis play ing an al -
ter na tive mea sure ment
(for ex am ple, ex ter nal
volts from the rear
panel BNC) the peak
me ter will con tinue to
rep re sent the Sen sor A
and/or B data. This is
use ful for mon i tor ing an
ex ter nal volt age on the
me ter, while peak ing
up a re sponse be ing
mon i tored by a sen sor,
such as RF out put.
