NOTE
Im me di ately af ter power- on, the “es ti mated op er at ing
time re main ing” dis played may not be genu ine, as the
bat tery re quires a few min utes to cal cu late the pres ent
rate of dis charge. An ac cu rate in di ca tion will be dis played
only af ter a few min utes of con tinu ous op era tion.
CHARGE Avail able only when the in stru ment is be ing pow ered by AC line
power or ex ter nal DC power greater than 21 volts. This se lec tion
starts the bat tery charg ing cy cle. Note that the in stru ment will
shut down dur ing the charg ing cy cle, and re start auto mati cally
when the charg ing is com pleted. A se ries of 10 beeps sig nals com -
ple tion of the charge cy cle.
Rear Panel Con trols for rear panel con nec tions are lo cated in the Rear Panel sub menu.
GPIB Sets the GPIB ad dress and emu la tion modes.
AD DRESS [ADDR]
Set the GPIB ad dress for the power me ter. The de fault is 13.
MODE [EMUL]
Se lects the power me ter emu la tion mode. Se lect from ML24XX
(na tive), HP 436A, HP 437B, HP 438A, or ML4803A modes.
If the em u la tion mode is changed from ML24XX (na tive) when in
CDMA mode, the sys tem will re set to stan dard read out mode.
GPIB em u la tion modes are not avail able in CDMA mode.
BUFFER [BUFF]
If BUFFER En abled is TRUE (de fault): In the ML24XX na tive
mode, 488.2 GPIB op er a tion, when a re quest for data is made the
re sponse is put in an out put buffer ready to be read by the con -
trol ler. If an other data re quest is made and the pre vi ous data has
not been read out of the out put buffer; the new data is queued af -
ter the orig i nal re quest. In this mode of op er a tion the GPIB re -
sponse buff er ing en able is TRUE, and fol low ing the 488.2
spec i fi ca tions, the re sponse should be read when ever a re quest
for data is made.
If BUFFER Enabled is FALSE: In this mode when ever a re quest
for data is made, (ex cept by se rial poll) the out put buffer is
cleared and the only data in the out put queue will be the re -
sponse to the last data re quest made. The out put buffer is cleared
once a valid GPIB data re quest com mand has been rec og nized.
ML2400A OM 4-31
OPERATION SYSTEM MENU
NOTE
BUFFER En abled
TRUE is the de fault.
Use FALSE when pro -
gram ming sim ple com -
mand se quences to
read data, and you do
not want to bother with
de cod ing sta tus or
keep ing track of mul ti -
ple re sults or read ings.
