LIMITS [MODLIM] – If this is set, and the lim its fail, then the
num ber spec i fied in the “phone num ber” field will be di aled. Re -
mote com mu ni ca tions can then con tinue as nor mal.
RANGE [MODRNG] – If this is set, and there is a sig nal chan nel
range er ror, then the num ber spec i fied in the “phone num ber”
field will be di aled. Re mote com mu ni ca tions can then con tinue as
nor mal.
POWER [MODPWR] – If this is set, and the power cy cles on the
me ter, then the num ber spec i fied in the “phone num ber” field
will be di aled. When a con nec tion is es tab lished, an SRQ will be
sent to the host PC. Re mote com mu ni ca tions can then con tinue
as nor mal.
BNC
[OBMD, OBCH,
OBVST, OBVSP,
OBDST, OBDSP,
OBCH, OBPL,
OBACM, OBCH,
OBZL, IBBLP]
Con fig ures the in put and out put rear panel BNC con nec tors.
PORT
Out put 1 or 2: Se lect the out put port to con fig ure (see MODE
be low).
In put 1: Se lect what type of Blanking in put you are pro vid ing
(see TTL LEVEL be low) on In put 1.
In put 2: Se lects in put 2 for V/GHz or Ex ter nal volts in put. You
can not con fig ure the V/GHz or Ex ter nal volts in put port here. To
con fig ure V/GHz set
Sen sor|CalFactor|Source to V/GHz. To use
the Ex ter nal Volts In put set
Chan nel|Setup|In put to EXT V.
MODE (out put ports only)
OFF (out put set to ground) port 1 or 2
Ana log OUT (ana log scaled out put) port 1 or 2 pro vides an out -
put volt age pro por tional to the mea sure ment.
RF Blank ing (output 2 only) pro vides a logic level out put dur ing
the ZERO process. This can be used to switch off RF from ex ter -
nal sources.
PASS/FAIL port 1 or 2 logic level output
ML2400A OM 4-33
OPERATION SYSTEM MENU
