Set tling (%) Power Level (dBm) Read ings/Sec ond
0.1 0 150
0.1 –30 150
10.0 0 610
10.0 –30 250
The 0.1% set tling on –30 dBm power level re sults were not im proved be cause
of the time needed to set tle to 0.1% at –30 dBm.
Us ing
Buff ered
Re quests
Us ing the buff ered Out put chan nel ON com mand (page 6-66 ), even faster
meas ure ment speeds can be achieved. By us ing the ON com mand in stead of
the O com mand x number of times, ex tra proc ess ing is re moved, re sult ing in
im proved speed.
NOTE
Us ing FAST mode here will not in crease the speed as this
mode only works when ask ing for one meas ure ment at a
time ( i.e., the ‘O’ com mand only.)
C code ex am ple:
/* Re set unit and ask for 200 buff ered read ings n chan nel 1 */
Send(0, 13, “* RST ; ON 1, 200”, 15L, NLend );
/* use a large buffer size (4K for 200 read ings) */
Re ceive(0, 13, buffer, 4096, STOPend );
Set tling (%) Power Level (dBm) Read ings/Sec ond
0.1 0 216
0.1 –30 202
Chang ing
meas ure ment modes
By chang ing the sen sor meas ure ment mode to Cus tom, the ML2400A Se ries
can be pre cisely con fig ured to meet the needs of the spe cific ap pli ca tion.
In this ex am ple, the Trig ger Gate Width (page 6-81 ) has been re duced to 1 ms,
Chan nel 1 is set to Sen sor A, and Chan nel 2 is off.
C code ex am ple:
/* re set unit. Cus tom meas ure ment mode, 1 ms TRGGW */
/* Auto av er ag ing Sen sor A Chan nel 2 off*/
/* Use FAST mode*/
Send(0, 13, “* RST ; FAST ON; SENMM A,
CUS TOM; TRGGW 1ms”, 51L, NLend );
5-
PROCEDURES OPTIMIZING READINGS
