1-11
Chapter 1 General Information
Electromagnetic Meets European community requirements for CE marking
Compatibility
Safety Conforms to EN 61010-1 for Class 1 portable equipment
Temperature:
Operating –10°C to 50°C, 85% humidity or less
Storage –50°C to +80°C
Power Dissipation 850 mW maximum
Dimensions
WxHxD 6.6cmx10.9 cm x 3.3 cm
(2.6 in x 4.3 in x 1.3 in)
Weight <0.45 kg (< 1 lb.)
* Specifications apply when connected to the Site Master.
General
Language Support: English, Spanish, French, German, Chinese, Japanese
Internal Trace Memory: Up to 300 traces
Setup Configurations: S331D: 10 to 30 setups (VNA-10, T1-5, E1-5, High Accuracy
Power Meter-5, Power Meter-5)
S332D: 15 to 40 setups (VNA-10, SPA/TM-5, Power Meter-5,
High Accuracy Power Meter-5, IA-5, Channel Scanner-5)
Display: Standard color TFT (640x480) display with
variable brightness control
Inputs and Outputs Ports:
RF Out: Type N, female, 50W
Maximum Input without Damage: +23 dBm, ± 50 VDC
RF In: Type N, female, 50W
Maximum Input without Damage: +43 dBm (Peak), ± 50 VDC
Ext. Trig In: BNC, female (5 V TTL)
Ext. Freq Ref In (2 to 20 MHz): Shared BNC, female, 50W, (–15 dBm to +10 dBm)
Serial Interface: RS-232 9 pin D-sub, three wire serial
Electromagnetic Compatibility: Meets European Community requirements for CE marking
Safety: Conforms to EN 61010-1 for Class 1 portable equipment
Temperature:
Operating: -10°C to 55°C, humidity 85% or less
Non-operating: –51°C to +71°C (store battery separately between 0°C and
+40°C for any prolonged non-operating storage period)
Power Supply:
External DC Input: +12.5 to +15 volt dc, 3A maximum
Internal: NiMH battery: 10.8 volts, 1800 mAh
Dimensions:
Size (wxhxd): 25.4 cm x 17.8 cm x 6.1 cm (10.0 in x 7.0 in x 2.4 in)
Weight: < 2.28 kg (< 5 lbs) including battery
Table 1-1. Performance Specifications (6 of 6)
