Technical Specifications
Environmental (Operating)
32°F to 130°F (0°C to 55°C), 5% to 95% R.H. (Non-Condensing)
Environmental (Storage)
-22°F to 158°F (-30°C to 70°C), 0% to 95% R.H. (Non-Condensing)
Input Power 24 VAC ±10%, 50/60 Hz, 21 VA Max (excluding external loads), Class 2
Inputs
4 Universal Inputs
Binary Input (Contact Closure)
Analog Input (0 – 10 VDC)
Thermistor Input (10k Type 2)
3 RJ45 Network Ports
Outputs
1 Analog Output (0 – 10 VDC, Max: 10 mA)
2 Binary Outputs, Non-Isolated Contact Closure (Max: 24 VAC, 500 mA)
Indicators
Touchscreen Display, 4.3 in. (109 mm) TFT, Speaker
Housing
UL 94V-0, PC-ABS Plastic
BACnet
Device Type B-AAC
Communication Type MS/TP (RS-485)
Communication Speed 9600, 19200, 38400, 76800
Certification BTL
Control Priority Order
1. BACnet
2. Normal operation
