GETTING STARTED WITH LUME20
In the Box
Room Pressure Monitor (LUME20)
Component
Quantity
Description
Room Pressure Monitor
(LUME20)
1
Single LUME20
[Optional] Differential Pressure Sensor (SDPT)
Component
Quantity
Description
Differential Pressure
Sensor
1 (single room monitoring)
2 (dual room monitoring)
3 (triple room monitoring)
Single SDPT
[Optional] Stainless Steel Sensor Plate
Component
Quantity
Description
Stainless Steel Sensor
Plate
2 (single room monitoring)
4 (dual room monitoring)
6 (triple room monitoring)
Stainless Steel Plate used as a
pressure sensor inlet
Mounting Hardware
Packet
2 (single room monitoring)
4 (dual room monitoring)
6 (triple room monitoring)
Packet containing two screws
for J-Box mounting of Sensor
Plate
Kink Resistant Air Tubing -
96 in. (2.44 m)
1 (single room monitoring)
2 (dual room monitoring)
3 (triple room monitoring)
Air pressure tubing to connect
between Sensor Plate and
Room Pressure Sensor
OR
[Optional] ABS Sensor Plate
Component
Quantity
Description
ABS Sensor Plate
2 (single room monitoring)
4 (dual room monitoring)
6 (triple room monitoring)
ABS plate used as pressure
sensor inlet
Mounting Hardware
Packet
2 (single room monitoring)
4 (dual room monitoring)
6 (triple room monitoring)
Packet containing two screws
and two drywall anchors for wall
mounting of Sensor Plate
Kink Resistant Air Tubing -
96 in. (2.44 m)
1 (single room monitoring)
2 (dual room monitoring)
3 (triple room monitoring)
Air pressure tubing to connect
between Sensor Plate and
Room Pressure Sensor
CAUTION
Please ensure you have all the components before proceeding. Inspect all components for shipping damage. Do not install any components that appear
damaged. Contact your local Antec Controls Representative for replacements.
For the latest information and videos please visit www.AntecControls.com.
