LUME20 - MANUAL
9 | LUME20Manual | AntecControls.com
Option C
Mount LUME20 using a standard single-gang electrical box.
STEP 1
Using the provided instructions, mount the standard single-gang electrical box at the
suggested height from the floor.
STEP 2
Mount the back plate to the box using two #8-32 screws.
STEP 3
Attach LUME20 on the backplate that was installed in Step 2.
