8
Set Up & Menu Configuration Options Sprint Pro
II. Set Up & Menu Configuration
Options
This section of the manual describes how to change the default configured
options if required, if not required please refer to Section III for details on
Performing Tests.
Fuel options
Sprint Pro displays the current fuel option during flue gas testing on the Flue
Gas Analysis screen.
To change the fuel option required, from the Main Menu select Fuel Options.
Use the soft keys
and to navigate the available fuels and select the
required fuel using the soft key.
The new fuel option will be displayed on the Flue Gas Analysis screen during
testing.
Fuel options available are: Natural gas, LPG, Heavy oil, Light oil, Coal, Wood,
Wood pellet dry, Coke, BioMass and Bagasse.
Note: NetHE only available for fuels natural gas, LPG, light oil and heavy oil.
Units of measurement
To change the units of pressure, temperature or efficiency from the Main Menu
select Units of Measurement.
Use the soft keys
and to navigate the available submenus and units and
select the required option using the soft key.
Select one of the following options.
Temperature: degrees Celsius (ºC) or degrees Fahrenheit (ºF).
Pressure: mBar, Pa, hPa, kPa, PSI, inWG, mmWG, inHG and mmHG. %
Efficiency: Net, Gross or NetHE.
Note: During flue gas analysis for High Efficiency/Condensing boilers Sprint Pro will
switch automatically to NetHE (Net High Efficiency) if Net Efficiency is selected.
The formulae and constants used for Gross and Net efficiency calculations
are those specified in EN50379. In general it is Net efficiency which is nor-
mally quoted. For modern condensing boilers the Net efficiency calculated may
