m. Altitude Sector: The altitude sector when the dive started.
n. Ascent Rate Indicator: The fastest ascent speed recorded during the dive. If
the maximum ascent rate was exceeded during the dive, the indicator
will also appear.
Logbook Page 2
o. Water temperature: The temperature recorded at the maximum depth.
p. Safety factor setting: The safety factor setting when dive was made
q. Average depth: The average depth of the dive.
r. Maximum depth: The deepest depth reached during the dive
Recorded violations
a. Decompression: If a decompression dive was made, the label will be
displayed; if the decompression stop was violated, the label will flash.
b. Fast ascent: If the ascent rate was violated, the label will flash.
c. PO
2
violation: If you exceed the maximum operating depth for either mix, the
label will flash.
d. Out of range: If a dive was made that exceeded the depth limit or at an altitude
over 6000m/19,685 ft., the entire display will flash.
(see figure 9)
(not shown)
