Parameter Function
Enable You need to draw a circle to enable motion detection function.
Sensitivity
There are six levels. The sixth level has the highest sensitivity.
Region
There are six levels. The sixth level has the highest sensitivity.
Region: If you select motion detection type, you can click this button
to set motion detection zone. The interface is shown as in Figure
7-41. There are PAL 22X18/NTSC 22X15 zones. Right click mouse
you can go to full-screen display mode. Do remember clicking OK
button to save your motion detection zone setup.
Period
Motion detection function becomes activated in the specified
periods.
There are six periods in one day. Please draw a circle to enable
corresponding period.
Select date. If you do not select, current setup applies to today only.
You can select all week column to apply to the whole week.
Click OK button, system goes back to motion detection interface;
please click save button to exit.
Anti-dither
System only memorizes one event during the anti-dither period. The
value ranges from 0s to 15s.
Normal
out
There is 2-channel alarm output.
Corresponding to motion detection alarm output port(multiple
choices)
Enable alarm activation function. You need to select alarm output
port so that system can activate corresponding alarm device when
alarm occurs.
Alarm
latch
System can delay the alarm output for specified time after alarm end
The value ranges from 10s to 300s.
Record
channel
System auto activates motion detection channel (multiple choices) to
record once alarm occurs (working with motion detection function).
Please note you need to go to Chapter 4.4 Schedule to set motion
detection record period and go to chapter 4.2 Manual Record to set
current period as auto record.
Record
latch
System can delay the record for specified time after alarm ended. The
value ranges from 10s to 300s.
Email If you enabled this function, System can send out email to alert you
when alarm occurs and ends.
Tour
Display the selected video in local monitor window.
This function is not available in current device.
PTZ
Activation
Here you can set PTZ movement when alarm occurs. Such as go to
preset x when there is an alarm.
Capture You need to input capture channel number so that system can backup
motion detection snapshot file.
Copy It is a shortcut menu button. You can copy current channel setup to
one or more (all) channels.
Save You can click save button after you complete setup for one channel,
or you can complete the whole setups and then click save button.
