Apollo HD Series User Manual

55
55
 Function: There are various devices for you to select. Console is for serial port or min-end
platform to upgrade program. Keyboard is for you to use special keyboard to control current
device.
 Baud rate: You can select proper baud rate.
 Data bit: You can select proper data bit.
 Stop bit: There are three values: 1/1.5/2.
 Parity: there are three choices: none/odd/even.
System default setup is:
 Function: Console
 Baud rate:115200
 Data bit:8
 Stop bit:1
 Parity: None
After completing all the setups please click save button, system goes back to the previous menu.
Figure 5-8
5.3.5 Network
Here is for you to input network information. See Figure 5-9.
 IP address: Here you can input IP address.
 DHCP: It is to auto search IP. When enable DHCP function, you can not modify IP/Subnet
mask /Gateway. These values are from DHCP function. If you have not enabled DHCP
function, IP/Subnet mask/Gateway display as zero. You need to disable DHCP function to
view current IP information. Besides, when PPPoE is operating, you can not modify
IP/Subnet mask /Gateway.
 TCP port: Default value is 37777.
 UDP port: Default value is 37778.
 HTTP port: Default value is 80.
 Max connection: system support maximal 10 users. 0 means there is no connection limit.
 Transfer mode: Here you can select the priority between fluency/video qualities.
 Network download: System can process the downloaded data first if you enable this function.
After completing all the setups please click save button, system goes back to the previous menu.

Apollo HD Series Specifications

General

Category	DVR
Video Compression	H.264
Hard Drive Capacity	Up to 6TB
Remote Viewing	Yes
Operating System	Embedded Linux
Video Input	4/8/16 channels
Recording Resolution	1080p/720p
Mobile Support	iOS, Android
