Apollo HD Series User Manual

11
11
 Alarm activation function
Several relay alarm outputs to realize alarm activation and on-site light control.
 Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC COM
to upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
 PTZ control
Support PTZ decoder via RS485.
Support various decode protocols to allow the PTZ to control the speed dome.
 Intelligent operation
Mouse operation function
In the menu, support copy and paste setup function
Slight function differences may be found due to different series.
1.3 Specification
Parameter
4-ch
8-ch
16-ch
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
Front panel, USB mouse, remote control
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
G.711A
Video monitor
Video Input
4-CH composite video
input: (NTSC/PAL)
BNC (1.0V
P- P,
75Ω)
8-CH composite video
input: (NTSC/PAL)
BNC (1.0V
P- P,
75Ω)
16-CH composite
video input:
(NTSC/PAL) BNC
(1.0V
P- P,
75Ω)
Video
Output
1-ch PAL/NTSC BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output;
1-ch HDMI output (Reserved port)
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (625 line, 50f/s), NTSC (525 line, 60f/s)
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel

Apollo HD Series Specifications

General

Category	DVR
Video Compression	H.264
Hard Drive Capacity	Up to 6TB
Remote Viewing	Yes
Operating System	Embedded Linux
Video Input	4/8/16 channels
Recording Resolution	1080p/720p
Mobile Support	iOS, Android
