Support monitor tour functions such as alarm, motion detection, and
Real-time monitor：
D1 704×576/704×480
Playback：
1/9-ch: D1 704×576/704×480 , CIF 352×288/ 352×240 , QCIF
176×144/176×120
Other channels CIF 352×288/ 352×240 、QCIF 176×144/176×120
Support dual streams: extra stream resolution QCIF 176×144/176×120
Motion
Detection
Zone setup: support max 396(22×18) zones.
Support various sensitivities.
6-level image quality (Adjustable)
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Channel information, time information and privacy mask zone.
TV Adjust Adjust TV output zone suitable to anamorphic video;
Channel
Lock
Cover secret channel with blue screen though system is encoding
normally.
Screen -lock function to prevent unauthorized user seeing secret video.
Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
4-ch 200-
2000mv10KΩ(BNC)
8-ch 200-
2000mv10KΩ(BNC)
4-ch 200-
2000mv10KΩ
1-ch audio output 200-3000mv 5KΩ(BNC)
Current series products do not support audio talk function.
1 built-in SATA port. Support 1 HDD.
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Record and
playback
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
1 to 120 minutes single record duration (Default 60 minutes)
When hard disk is full, system can overwrite previous video file.
Record
Various search engines such as time, type and channel.
Various fast play, slow play speeds, manual frame by frame playback
and reverse play mode.
