Apollo HD Series User Manual

110
110
Frame rate You can select from the dropdown list. The value ranges from
1f/s to 7f/s.
Resolution
You can select from the dropdown list.
For 16 series DVR:
Channel 1 and channel 9 support D1/CIF/QCIF.
Channel 2 to channel 8, channel 10 to channel 16 supports
CIF/QCIF.
Quality
You can select from the dropdown list. Here is for you to set
video quality.
There are six options: 10％、30％、50％、60％、80％、
100％.
100% is the best quality.
7.3.3.7 Abnormity
The abnormity interface is shown as below.
Figure 7-50
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type

The abnormal events include: no disk, no space, disk error, net eeror.

You need to draw a circle to enable this function.
Normal
Out
The corresponding alarm activation output channel when alarm occurs,
There are three channels. The 3-ch is the controllable 12V output.
Latch The alarm output can delay for the specified time after alarm stops.
Then system disables alarm and corresponding activation output.
The value ranges from 10s to 300s.
Send
email
If you enable this function, system can send out email to alarm the
specified user.

Apollo HD Series Specifications

General

Category	DVR
Video Compression	H.264
Hard Drive Capacity	Up to 6TB
Remote Viewing	Yes
Operating System	Embedded Linux
Video Input	4/8/16 channels
Recording Resolution	1080p/720p
Mobile Support	iOS, Android
