Parameter Function
Max Connection Network user max amount. The value ranges from 0 to 10.
O means there is no user can access current device.
Remote
Host
Multiple
cast
group
Set MULCAST address and port.
Enable MULCAST function.
PPPOE
Input the PPPoE user name and password you get from the
IPS (internet service provider) and enable PPPoE function.
Please save current setup and then reboot the device to
get the setup activated.
Device connects to the internet via PPPoE after reboot.
You can get the IP address in the WAN from the IP address
column.
Please note if you want to reboot the device please make
sure you have proper reboot right and there is no login user
in current device.
Email
The email interface is shown as in Figure 7-33.
Figure 7-33
Please refer to the following sheet for detailed information.
Parameter Function
SMTP Server
Input server address and then enable this function.
Port Default value is 25. You can modify it if necessary.
User Name
