Preparing and Running the Micro Fluidic Cards (PCR)
Applied Biosystems Micro Fluidic Card Getting Started Guide 27
4. Use the barcode and the notched corner on the Micro Fluidic
Card’s carrier to determine the proper orientation of the
Micro Fluidic Card for the 7900HT system.
5. Place the Micro Fluidic Card into the 7900HT system as
shown below.
To place the Micro Fluidic Card in the
7900HT system: (continued)
GR2164
Barcode
Notched
corner
GR2165
To Next Page
