APS APS-3000P Series - Electrical and Isolation Specifications

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-3000P Series 2 - 3 OM-001-03000-00P-03.9
Input Electrical Specifications
Model
3003P
3006P
3009P
3015P
3030P
3060P
3090P
3120P
3150P
3180P
Input Phase
1-phase/ 2-wire +
Gnd
3-phase
Input Voltage (VAC L/L)
230 V ± 15%
208, 220, 240(3-W+G) 380,415,480(4-W+G) 10%
Input Frequency
47 – 63 Hz
Output Electrical Specifications
Rated Power
(see W-Hz
chart)
Total Power
3 KVA
6 KVA
9
KVA
15KVA
30KVA
60KVA
90KVA
120KVA
150kVA
180kVA
Per Phase
1 KVA
2 KVA
3 KVA
5 KVA
10KVA
20KVA
30KVA
40KVA
50kVA
60kVA
Max. Amps per
phase
0 – 150 V
8.4 A
16.8 A
25.2 A
42.0 A
84.0 A
168.0
A
252.0
A
366.0A
417.0 A
500.0A
0 – 300 V
4.2 A
8.4 A
12.6 A
21.0 A
42.0 A
84.0 A
126.0
A
168.0
208.0 A
250.0A
Phase
3-phase / 4-wire + Ground
Voltage
Line to Neutral
0 – 150 V / 0 – 300 V Selectable
Line to Line
0 – 260 V / 0 – 520 V Selectable
Resolution
0.1 V
Accuracy
 (1% + 0.2 V)
Frequency
Range
45 – 500 Hz
Resolution
0.1 Hz at 45 – 99.9 Hz, 1 Hz at 100 – 500 Hz
Accuracy
 0.2%
Per Phase Parameters
3003P
3006P
3009P
3015P
3030P
3060P
3090P
3120P
3150P
3180P
Current
Per
Phase
Range
L
0.000 – 3.5 A
0.00 – 35.00 A
H
3.00 – 35.00 A
30.00 – 350.0 A
Resolution
L
0.001 A
0.01 A
H
0.01 A
0.1 A
Accuracy
L
 (1% of reading +
0.005 A)
 (1% of reading + 0.02 A)
H
 (1% of reading + 0.01
A)
 (1% of reading + 0.1 A)
Power
Per
Phase
Range
L
0.0 – 350.0 W
0.000 – 3.500 kW
H
300 – 4000 W
3.00 – 60.00 kW
Resolution
L
0.1 W
0.001 kW
H
1 W
0.01 kW
Accuracy
L
 (1.5% of reading +
0.5 kW)
 (1.5% of reading + 0.005 kW)
H
 (1.5% of reading +
1.0 kW)
 (1.5% of reading + 0.01 kW)
Power
Factor
Range
0.001 – 1.000
Resolution
0.001
Accuracy
Depends on the accuracy of V, A, W
Harmonic Distortion
 1% (Resistive Load)
Crest Factor
 3 to 1
Load Regulation
 0.5%
Protection
Over-Current, Short-Circuit, Over-Temperature
Efficiency
 85% (at full load)
