CHAPTER 3
UNIT DESCRIPTION
Entire Contents Copyright 2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-3000P Series 3 - 1 OM-001-03000-00P-03.9
Chapter 3
Unit Description
Overview
Chapter 3 helps you locate controls and understand their functions. More importantly,
the names used throughout this manual to identify controls and functions are defined.
You need to know the vocabulary of the APS-3000P Series to take full advantage of
the information in this manual. Information in this chapter is in three sections:
Location and function of front panel displays and controls
Cabinet controls and connectors
Chassis features and details
Use the information in this chapter to gain a general understanding of the locations and
functionality of indicators, controls, connectors, and mechanical details of your APS-
3000P unit.
Front Panel Organization
The front panel of your APS-3000P unit is organized for efficiency of operation. It is
laid out to simplify operation in a test environment. The layout features:
4 Display Groups
Frequency Display
Voltage Display
Current Display
Multimeter Display
16 7-segment Display Indicators
16 Pushbutton Switches
20 LED Indicators
