APS APS-3000P Series - Mechanical and Environmental Specifications

CHAPTER 2
TECHNICAL SPECIFICATIONS
Entire Contents Copyright  2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-3000P Series 2 - 6 OM-001-03000-00P-03.9
Mechanical Specifications
Model
3003
3006
3009
3015
3030
3060
3090
3120
3150
3180
Power Rating (kVA)
3
6
9
15
30
60
90
120
150
180
Dimensions (In.):H
34
34
34
34
38
65
71
71
71
71
D
26
26
36
36
39
39
39
47
47
47
W
17
17
24
24
24
32
48
48
63
63
Weight Kg
140
175
299
362
547
909
1505
2139
1800
1800
lbs
305
385
659
798
1206
2004
3318
4716
3968
3968
Displays and Controls
Model
3003
3006
3009
3015
3030
3060
3090
3120
3150
3180
4 Digital LED meters
Frequency, Voltage, Current, Power or Power Factor (simultaneously)
PLC Remote
Output ON/OFF
Selection of programmable memories: P1, P2, P3
Memory
8 Memories, 5 Programmable Steps per Memory for:
Voltage, Frequency, and Current Limit
Calibration
Front Panel Calibration
PLC (external)
Interface
PLC interface controls execution of programmed steps in Memories 1, 2, or 3.
The PLC interface is a standard feature of all APS Power Converters.
Serial Data Interface
Either RS-232 or
GPIB
Both RS-232 and GPIB serial data interfaces allow execution of remote commands. Access
to and recording of active test data is possible. A serial data interface has read/write access
to all of the 8 Programmable Memories.
Note: Only one type of serial data interface can be installed: RS-232 or GPIB.
Auto-Voltage Adjust
Provides improved voltage regulation
Environmental Specifications
Operating Temperature
32 ºF – 104 ºF (0 ºC – 40 ºC)
Relative Humidity
< 80 % (Non-condensing)
Altitude
≤ 6,500 feet
