Low-Voltage Mode (U-LO) Calibration
1. At the FREQUENCY Display, press the ︿ or ﹀ buttons to select
(V-LO).
The low-voltage parameter is calibrated (first) at the beginning of calibration.
2. At the OUTPUT Terminals, with no load attached, carefully connect a certified,
calibratedTrue RMS voltmeter, of at least 0.2% accuracy, to the output of Phase R
(US = A). After calibrating Phase R, you will repeat this step for Phases S and T.
3. At the MULTIMETER Display, press the TEST button. The APS unit will
automatically perform a low-voltage output reading and will output approximately
150 VAC. The external RMS voltmeter will display the actual voltage output, and
the current display will show the calibration value (see Calibration Table below).
4. At the CURRENT Display Adjust the voltage using the CURRENT ︿ or ﹀
buttons until the metered values match.
5. At the MULTIMETER Display, press the LOCK button to finish low-voltage
calibration.
6. Proceed to the next calibration function, unless this completes system calibration.
7. Note, to exit the Calibration Mode, your APS system must be restarted after you
have completed ALL calibration operations.
