Cabinet Controls and Connections
The APS-3000P controls and connections are conveniently located for ease of use and
accessibility. Included are:
 Power ON/OFF
 PLC Control Port
 RS-232 Serial Data / Control Port
 GPIB Parallel Data / Control Port
 Input Power Connection
 Input Power Circuit Breaker
 Output Power Connection
 Output Power Circuit Breaker
See the following page for illustrations. The Cabinet Controls Table on page 3-9
provides additional information about each of these items.
Chassis Details
The APS-3000P is built on a rugged chassis for use in demanding test environments.
Important elements of the design include:
 Handles
 Wheels
 Fans
 Vents
See the following page for illustrations. The Chassis Details Table on page 3-9 provides
additional information about each of these items.
