Multimeter Selection
MULTIMETER display
Displays Power, Power Factor, Testing Time, or Program-Step.
P indicator
When ON, MULTIMETER displays output Power (kW).
PF indicator
When ON, MULTIMETER displays Power Factor.
T indicator
When ON, MULTIMETER displays Testing Time.
P-S indicator
When ON, MULTIMETER displays the current PROGRAM MEMORY
status (index of Program-Step).
TEST button
Start output or starts AutoRun program.
RESET button
Stop output or start auto self-test program.
LOCK / LOCAL button
Toggles between locked / unlocked state for the panel, using LOCAL
button to leave the programmable mode.
METER button
Switches between the display of P (Power), PF (Power Factor),
T (Testing Time), and P-S (Program-Step).
APS-3000P Multimeter Display
M U L T I M E T E R
TEST RESET
P
PF
T
P - S
METER
/LOCAL
LOCK
