RS-232 Command and Control Functions
The following three tables list the APS-3000P RS-232 commands and queries:
 Front Panel and RS-232 Command Functions
 RS-232 System Control Functions
 RS-232 Program Functions
Front Panel and RS-232 Command Functions
NOTE
RS-232 COMMAND
TEST
TEST
Power ON
RESET
RESET
Power OFF
METER X
METER X
0 = P
Refers to the front panel
Multimeter
1 = PF
2 = T
3 = P-S
METER?
METER?
RANG X
RANG X
0 = Low 0-150V
APS-3000P Series units
have two voltage ranges.
1 = High 0-300V
RANG?
RANG?
TD?
TD?
BY PHASE
FREQ,V,I,W,PF,TIMER
TDR?
TDR?
PHASE R METER
FREQ,V,I,W,PF,TIMER
TDS?
TDS?
PHASE S METER
FREQ,V,I,W,PF,TIMER
TDT?
TDT?
PHASE T METER
FREQ,V,I,W,PF,TIMER
TDC?
TDC?
PHASE Σ METER
FREQ,V,I,W,PF,TIMER
PHASE X
PHASE X
0=R
1=S
Refers to the front panel
Meters
2=T
3= Σ
PHASE?
PHASE?
