CHAPTER 3
UNIT DESCRIPTION
Entire Contents Copyright  2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-3000P Series 3 - 9 OM-001-03000-00P-03.9
APS-3000P Series Unit (example)
Front View
Rear View
Input Power
Circuit Breaker
Input Power
Terminals
(see page 1-7)
Output Power
Circuit Breaker
Output Power
Terminals
(see page 1-7)
Instrumentation
Air Vents
Exhaust Fans (4)
PLC
External Input
(Control P1, P2, P3)
GPIB or RS-232
External
Input / Output
Main
Power Switch
Front Panel Control & Displays
• Frequency
• Voltage
• Current
• Multimeter
Main Air Intake Vents
Handles
WARNING
DO NOT use handles for lifting.
Front Wheels
Lock / Unlock
And Swivel
Rear Wheels
Fixed Position
