Binary inputs
The C232 has optical coupler inputs for processing binary signals from the system. The
number and connection schemes for the available binary inputs are shown in the
terminal connection diagrams. The Address List gives information about the
configuration options for all binary inputs.
The C232 identifies the installed modules during startup. If any binary signal inputs are
not included, the configuration addresses of the missing binary signal inputs are
automatically shielded so that they do not appear in the menu tree.
When configuring binary inputs one should keep in mind that the same function can be
assigned to several signal inputs. Thus one function can be activated from several
control points having different signal voltages.
The configuration of C232 will be changed with the selection of a new bay type!
For C232 the assignement of designators to the binary inputs is given in the following
table:
Model 1 Model 2 Model 3 Model 4 Model 4 with
additional I/O
Binary
inputs
U 201 U 201 U 201 U 201 U 201 U 2A
U 202 U 202 U 202 U 202 U 202 U 2B
U 203 U 203 U 203 U 203 U 203 U 2C
U 204 U 204 U 204 U 204 U 204 U 2D
U 205 U 205 U 205 U 205 U 205 U 2E
U 206 U 206 U 206 U 206 U 206 U 2F
U 213 U 207 U 207 U 213 U 207 U 2G
U 214 U 208 U 208 U 214 U 208 U 2H
U 215 U 209 U 209 U 215 U 209 U 2I
U 216 U 210 U 210 U 216 U 210 U 2J
- U 213 U 211 U 220 U 211 U 2K
- U 214 U 212 - U 212 U 2L
- U 215 U 213 - U 213 U 2M
- U 216 U 214 - U 214 U 2N
- U 217 U 215 - U 215 U 2O
- U 218 U 216 - U 216 U 2P
- U 219 U 217 - U 217 U 2Q
- - U 218 - U 218 U 2R
- - U 219 - U 219 U 2S
- - U 220 - U 220 U 2T
The configuration of binary inputs for each bay type is given in the List of Bay Types in
the Appendix.
Note: Before selecting a new bay type, make sure that only functions of function
groups DEVxx are configured for the binary inputs. Otherwise there will be
an error message, and the new bay type will not be activated.
Note: Before selecting a new bay type, make sure that all binary inputs specified in
the List of Bay types for the selected bay type are actually available in the
device. Otherwise there will be an error message, and the new bay type will
not be activated.
