Areva MiCOM C232 - 8.1.3 Operating Data Recording

8 Information and Control Functions
(continued)
8-20
C232-302-401/402/403/404-603 / C232/EN M/A23
Operating data recording
OP_RC: Reset recording
100 001
Fig. 3-64
The operating data memory and the counter for operation signals are reset.
Monitoring signal recording
MT_RC: Reset recording
003 008
Fig. 3-65
Reset of the monitoring signal memory.
Fault recording
FT_RC: Trigger USER
003 041
Fig. 3-69
Fault recording is enabled from the local control panel for 500 ms.
FT_RC: Reset recording
003 006
Fig. 3-70
Reset of the following memories:
 LED indicators
 Fault memory
 Fault counter
 Fault data
 Recorded fault values
Logic
LOGIC: Trigger 1
034 038
Fig. 3-98
LOGIC: Trigger 2
034 039
Fig. 3-98
LOGIC: Trigger 3
034 040
Fig. 3-98
LOGIC: Trigger 4
034 041
Fig. 3-98
LOGIC: Trigger 5
034 042
Fig. 3-98
LOGIC: Trigger 6
034 043
Fig. 3-98
LOGIC: Trigger 7
034 044
Fig. 3-98
LOGIC: Trigger 8
034 045
Fig. 3-98
Intervention in the logic at the appropriate point by a 100 ms pulse.
Binary counts
COUNT: Transmit counts USER
217 008
Fig. 3-117
Count transmission.
COUNT: Reset USER
217 003
Fig. 3-117
Count reset.
8.1.3 Operating Data Recording
Operating data recording
OP_RC: Operat. data record.
003 024
Fig. 3-64
Point of entry into the operating data log.
Monitoring signal recording
MT_RC: Mon. signal record.
003 001
Fig. 3-65
Point of entry into the monitoring signal log.
