7 Settings
(continued)
7-4
C232-302-401/402/403/404-603 / C232/EN M/A23
7.1.2 Configuration Parameters
Local control panel
LOC: Language
003 020
Language in which texts will be displayed on the local control panel.
LOC: Decimal delimiter
003 021
Character to be used as decimal delimiter on the local control panel.
LOC: Password
003 035
The password to be used for changing settings from the local control panel
can be defined here. Further information on changing the password is
given in Chapter 6.
LOC: Password L/R
221 040
The password to be entered on the local control panel for switching from
remote to local control can be defined here. Further information on
changing the password is given in Chapter 6.
LOC: Displ. ext.dev.desig
221 032
Fig. 3-2
This setting defines whether the external device designations shall be
displayed on the Bay Panel.
LOC: Display L/R
221 070
Fig. 3-2
This setting defines whether the control site – local or remote – shall be
displayed on the Bay Panel.
LOC: Displ. interl. stat.
221 071
Fig. 3-2
This setting defines whether the "Locked" or "Unlocked" status shall be
displayed on the Bay Panel.
LOC: Designation busbar 1
221 033
Fig. 3-2
LOC: Designation busbar 2
221 034
LOC: Designation busbar 3
221 043
Setting for the busbar designations to be displayed on the Bay Panel.
LOC: Designat. bus sect.1
221 035
Fig. 3-2
LOC: Designat. bus sect.2
221 036
Setting for the busbar section designations to be displayed on the Bay
Panel.
LOC: Character set
221 038
Fig. 3-2
The user can choose between several character sets for representing
switchgear units and their switching states on the Bay Panel. The symbols
assigned to the character sets are shown in Chapter 6: Local Control Panel.
Note:
Character set 3 is identical to character set 1 in the factory default setting,
but can be replaced by a user-defined character set – by using a special
S&R-103 accessory tool.
LOC: Fct. assign. L/R key
225 208
Fig. 3-5
This setting determines whether the switching (using either the L/R key or
the key switch) is between local and remote control (L↔R) or between
local+remote and local control (R&L↔L).
LOC: Assignment read key
080 110
Selection of the event log that will be displayed when the read key (log key)
is pressed.
