7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-5
LOC: Fct. Operation Panel
053 007
Fig. 3-3
Definition of the values to be displayed on the Measured Value Panel
referred to as the Operation Panel.
LOC: Fct. Fault Panel
053 003
Fig. 3-4
Definition of the values to be displayed on the Fault Panel.
LOC: Fct.asg. num. displ.
221 041
Fig. 3-2
Definition of the measured values to be displayed on the Bay Panel in
numerical form.
LOC: Fct. asg. bar displ.
221 042
Fig. 3-2
Definition of the measured values to be displayed on the Bay Panel in bar
form.
Note:
Measured values to be displayed in bar form must also be selected for
display as numerical measured values.
However, not all measured values that can be displayed in numerical form
can also be displayed in bar form! In such cases, a dummy or placeholder
must be included in the selection list for the bar display at the same point at
which a measured value that cannot be displayed in bar form appears in the
selection list for numerical measured values.
Example:
Current I
B
is to be displayed. In this case, either the primary current I
A
or
the per-unit current I
A
shall be selected for the numerical display. The per-
unit current I
B
shall be entered at the same position in the selection list for
the bar display.
LOC: Bar display type
221 039
Fig. 3-2
Deactivation of the bar display or definition of the orientation of the bar for
display of measured values on the Bay Panel.
LOC: Scal. bar display I
221 044
Fig. 3-2
Selection of the current for the 100% display.
LOC: Scal. bar display V
221 045
Fig. 3-2
Selection of the voltage for the 100% display.
LOC: Display bar scale
221 046
Fig. 3-2
Enabling and disabling the scaling display.
LOC: Hold-time for Panels
031 075
Fig. 3-3
Setting for the time period for which a panel is displayed before the unit
switches to the next panel. This setting is only relevant if more values are
selected for display than can be shown on the LCD display.
LOC: Autom. return time
003 014
Fig. 3-3
If the user does not press a key on the local control panel during this set
time period, the change-enabling function is deactivated and the Bay Panel
is called up.
LOC: Return time select.
221 030
Fig. 3-3
If the user does not press a key on the local control panel during this set
time period, then the selection of a switchgear unit is canceled.
LOC: Return time illumin.
003 023
If the user does not press a key on the local control panel during this set
time period, then the backlighting of the LCD display is switched off, and
any switchgear selection that might have been made is canceled.
