8 Information and Control Functions
(continued)
8-22
C232-302-401/402/403/404-603 / C232/EN M/A23
8.2.2 Measured Fault Data
Fault data acquisition
FT_DA: Fault duration
008 010
Fig. 3-66
Display of the fault duration.
FT_DA: Running time
004 021
Fig. 3-66
Display of the running time.
FT_DA: Fault current P p.u.
004 025
Fig. 3-68
Display of the fault current referred to I
nom
.
FT_DA: Fault curr. N p.u.
004 049
Fig. 3-68
Display of the ground fault current referred to I
N,nom
.
8.2.3 Fault Data Acquisition
FT_RC: Fault recording 1
003 000
Fig. 3-70
FT_RC: Fault recording 2
033 001
Fig. 3-70
FT_RC: Fault recording 3
033 002
Fig. 3-70
FT_RC: Fault recording 4
033 003
Fig. 3-70
FT_RC: Fault recording 5
033 004
Fig. 3-70
FT_RC: Fault recording 6
033 005
Fig. 3-70
FT_RC: Fault recording 7
033 006
Fig. 3-70
FT_RC: Fault recording 8
033 007
Fig. 3-70
Point of entry into the fault log.
