14 Order Information
14-1
C232-302-401/402/403/404-603 / C232/EN M/A23
C232
Designs Order No.
Compact Bay Unit for Control and Monitoring C232 C232- 0
-302 -603
-XXX
Compact case 9
Wall-mounting and fush-mounting, local HMI with graphic LCD 9
Model 1 1 0 0 0 0 -401
1 two-pole switching command with checkback signals
2 two-pole breaker position indications
or 4 free inputs
and 4 free inputs
Model 2 2 0 0 -402
3 two-pole switching command with checkback signals
2 two-pole breaker position indications
or 4 free inputs
and 4 free inputs
Model 3 3 0 -403
6 two-pole switching command with checkback signals
and 8 free inputs
Model 4 4 0 0 -404
with overcurrent protection
3 two-pole switching command with checkback signals
5 free inputs and 2 free outputs
with additional I/O extension 4 1 -404
6 two-pole switching command with checkback signals
8 free inputs
Measured value acqusition (transformer connection)
without 00
1 x 1A (Models 2 and 3 only) 1 0
1 x 5A (Models 2 and 3 only) 2 0
3 x 1A, 1 x 100V (Model 3 only) 0 1
3 x 5A, 1 x 100V (Model 3 only) 0 2
1 x 1A, 3 x 100V (Model 3 only) 0 3
1 x 5A, 3 x 100V (Model 3 only) 0 4
3 x 1A, 1 x 100V (Model 4 only) 0 6
3 x 5A, 1 x 100V (Model 4 only) 0 8
Measured value acquisition (0...20mA)
without 0
with (Model 2,3 and 4 [404] only) 1
with communication interface -456 9 2
Protocol settable:
IEC 60870-5-101/-103, Modbus, DNP 3.0
Channel 1 and 2: wire leads, RS485, isolated 1
Channel 1: plastic fiber, FSMA; Channel 2: wire leads, RS485, isolated 2
Channel 1: glass fiber, ST; Channel 2: wire leads, RS485, isolated 4
Channel 1: wire leads, RS485, isolated 5
Channel 1: plastic fiber, FSMA 6
Channel 1: glass fiber, ST 7
Language: English (German) without order code
Language: German (English) <1> -801
Language: French (English) <1> -802
Language: Spanish (English) <1> -803
Acceptance test certificate
according to EN10204-2.1/DIN 50049-2.1 to be ordered in plain text
<1> Must be ordered prior to device production
