6.5.2 Switching Between Address Mode and Plain Text Mode
The display on the local control panel can be switched between address mode and plain
text mode. In the address mode the display shows setting parameters, signals, and
measured values in numerically coded form, that is, as addresses. In plain text mode
the setting parameters, signals, and measured values are displayed in the form of plain
text descriptions. In either case, control is guided by the menu tree. The active branch
of the menu tree is displayed in plain text in both modes. In the following examples, the
display is shown in only plain text mode.
Control Step / Description Control
Action
Display
0 In this example, the user switches from plain
text mode to address mode.
Par/Func/Glob/MAIN
Device on-line
No (=off)
1 To switch from address mode to plain text
mode or vice versa, press the CLEAR key
C
and either the ‘left’ key or the ‘right’ key
simultaneously. This can be done at any point
in the menu tree.
C
+
or
C
+
Par/Func/Glob/MAIN
003.030
0
