Areva MiCOM C232 - 8.1.1.3 Logic State Signals

8 Information and Control Functions
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 8-7
8.1.1.3 Logic State Signals
Local control panel
LOC: Illumination on EXT
037 101
LOC: Loc.acc.block.active
221 005
Fig. 3-5
LOC: Rem.acc.block.active
221 004
Fig. 3-5
“Logical” communication
interface 1
COMM1: Command block. EXT
003 173
Fig. 3-7, 3-8,
3-9, 3-10,
3-11
COMM1: Sig./meas. block EXT
037 074
Fig. 3-8,
3-9, 3-10
COMM1: Command blocking
003 174
Fig. 3-7, 3-8,
3-9, 3-10,
3-11, 3-12
COMM1: Sig./meas.val.block.
037 075
Fig. 3-8,
3-9, 3-10
COMM1: IEC 870-5-103
003 219
Fig. 3-8
COMM1: IEC 870-5-101
003 218
Fig. 3-9
COMM1: IEC 870-5,ILS
003 221
Fig. 3-10
COMM1: MODBUS
003 223
Fig. 3-11
COMM1: DNP3
003 230
Fig. 3-12
Measured data input
MEASI: Enabled
035 008
Fig. 3-17
MEASI: Overload 20mA input
040 191
Fig. 3-20
MEASI: Open circ. 20mA inp.
040 192
Fig. 3-30
Binary outputs
OUTP: Block outp.rel. EXT
040 014
Fig. 3-22
OUTP: Reset latch. EXT
040 015
Fig. 3-22
OUTP: Outp. relays blocked
021 015
Fig. 3-22
OUTP: Latching reset
040 088
Fig. 3-22
Main function
MAIN: Enable protect. EXT
003 027
Fig. 3-37
MAIN: Disable protect. EXT
003 026
Fig. 3-37
MAIN: System IN enable EXT
040 130
Fig. 3-38
MAIN: Syst. IN disable EXT
040 131
Fig. 3-38
MAIN: Test mode EXT
037 070
Fig. 3-61
MAIN: Blocking 1 EXT
040 060
Fig. 3-42
MAIN: Blocking 2 EXT
040 061
Fig. 3-42
MAIN: Reset latch.trip EXT
040 138
Fig. 3-50
MAIN: Trip cmd. block. EXT
036 045
Fig. 3-50
MAIN: Switch dyn.param.EXT
036 033
Fig. 3-39
MAIN: CB closed sig. EXT
036 051
Fig. 3-45
MAIN: Man.cl.cmd.enabl.EXT
041 023
Fig. 3-45
MAIN: Manual close EXT
036 047
MAIN: Man. close cmd. EXT
041 022
Fig. 3-45
MAIN: Man. trip cmd. EXT
037 018
Fig. 3-51
MAIN: Reset indicat. EXT
065 001
Fig. 3-59
MAIN: Min-pulse clock EXT
060 060
Fig. 3-58
MAIN: Prot. ext. enabled
003 028
Fig. 3-37
MAIN: Prot. ext. disabled
038 046
Fig. 3-37
MAIN: Gen. trip signal
036 251
Fig. 3-50
MAIN: Syst.IN ext/user en.
040 132
Fig. 3-38
MAIN: System IN enabled
040 133
Fig. 3-38
MAIN: System IN disabled
040 134
Fig. 3-38
MAIN: Device not ready
004 060
Fig. 3-43
