8 Information and Control Functions
(continued)
8-6
C232-302-401/402/403/404-603 / C232/EN M/A23
Binary outputs
OUTP: State K 201
157 001
OUTP: State K 202
157 005
OUTP: State K 203
157 009
OUTP: State K 204
157 013
OUTP: State K 205
157 017
OUTP: State K 206
157 021
OUTP: State K 207
157 025
OUTP: State K 208
157 029
OUTP: State K 209
157 033
OUTP: State K 210
157 037
OUTP: State K 211
157 041
OUTP: State K 212
157 045
OUTP: State K 213
157 049
OUTP: State K 214
157 053
The state of the output relays is displayed as follows:
 Without function: No functions are assigned to the output relay.
 Low: The output relay is not energized.
 High: The output relay is energized.
This display appears regardless of the operating mode set for the output
relay.
LED indicators
LED: State H 2
085 000
LED: State H 3
085 003
LED: State H 4
085 006
LED: State H 5
085 009
LED: State H 6
085 012
LED: State H 7
085 015
LED: State H 8
085 018
LED: State H 9
085 021
LED: State H 10
085 024
LED: State H 11
085 027
LED: State H 12
085 030
The state of the LED indicators is displayed as follows:
 Inactive: The LED indicator is not energized.
 Active: The LED indicator is energized.
