8 Information and Control Functions
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 8-5
8.1.1.2 Physical State Signals
Binary inputs
INP: State U 201
178 001
INP: State U 202
178 005
INP: State U 203
178 009
INP: State U 204
178 013
INP: State U 205
178 017
INP: State U 206
178 021
INP: State U 207
178 025
INP: State U 208
178 029
INP: State U 209
178 033
INP: State U 210
178 037
INP: State U 211
178 041
INP: State U 212
178 045
INP: State U 213
178 049
INP: State U 214
178 053
INP: State U 215
178 057
INP: State U 216
178 061
INP: State U 217
178 065
INP: State U 218
178 069
INP: State U 219
178 073
INP: State U 220
178 077
The state of the binary signal inputs is displayed as follows:
Without function: No functions are assigned to the binary signal input.
Low: Not energized.
High: Energized.
This display appears regardless of the setting for the binary signal input
mode.
