8 Information and Control Functions
(continued)
8-4
C232-302-401/402/403/404-603 / C232/EN M/A23
MAIN: Voltage VPP,max p.u.
008 045
Fig. 3-33
Display of the maximum phase-to-phase voltage referred to V
nom
.
MAIN: Voltage VPP,min p.u.
009 045
Fig. 3-33
Display of the minimum phase-to-phase voltage referred to V
nom
.
MAIN: Voltage A-B p.u.
005 045
Fig. 3-33
Display of the updated value for phase-to-phase voltage A-B referred to
V
nom
.
MAIN: Voltage B-C p.u.
006 045
Fig. 3-33
Display of the updated value for phase-to-phase voltage B-C referred to
V
nom
.
MAIN: Voltage C-A p.u.
007 045
Fig. 3-33
Display of the updated value for phase-to-phase voltage C-A referred to
V
nom
.
MAIN: Active power P p.u.
004 051
Fig. 3-34
Display of the updated value for active power referred to nominal apparent
power S
nom
.
MAIN: Reac. power Q p.u.
004 053
Fig. 3-34
Display of the updated value for reactive power referred to nominal
apparent power S
nom
.
MAIN: Active power factor
004 054
Fig. 3-34
Display of the updated active power factor.
MAIN: Load angle
004 115
Fig. 3-34
Display of the updated load angle value.
Binary counts
COUNT: Count 1
217 100
Fig. 3-117
Display of the updated count.
