8 Information and Control Functions
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 8-3
MAIN: Active power P prim.
004 050
Fig. 3-34
Display of the updated active power value as a primary quantity.
MAIN: Reac. power Q prim.
004 052
Fig. 3-34
Display of the updated reactive power value as a primary quantity.
MAIN: Act.energy outp.prim
005 061
Fig. 3-36
Display of the updated active energy output as a primary quantity.
MAIN: Act.energy inp. prim
005 062
Fig. 3-36
Display of the updated active energy input as a primary quantity.
MAIN: React.en. outp. prim
005 063
Fig. 3-36
Display of the updated reactive energy output as a primary quantity.
MAIN: React. en. inp. prim
005 064
Fig. 3-36
Display of the updated reactive energy input as a primary quantity.
MAIN: Current IP,max p.u.
005 051
Fig. 3-30
Display of the maximum phase current referred to I
nom
.
MAIN: IP,max p.u.,delay
005 037
Fig. 3-30
Display of the delayed maximum phase current referred to I
nom
.
MAIN: IP,max p.u.,stored
005 035
Fig. 3-30
Display of the delayed stored maximum phase current referred to I
nom
.
MAIN: Current IP,min p.u.
005 056
Fig. 3-30
Display of the minimum phase current referred to I
nom
.
MAIN: Current A p.u.
005 041
Fig. 3-30
Display of phase current A referred to I
nom
.
MAIN: Current B p.u.
006 041
Fig. 3-30
Display of phase current B referred to I
nom
.
MAIN: Current C p.u.
007 041
Fig. 3-30
Display of phase current C referred to I
nom
.
MAIN: Current Σ(IP) p.u.
005 011
Fig. 3-30
Display of the calculated resultant current referred to I
N,nom
.
MAIN: Voltage VPG,max p.u.
008 043
Fig. 3-33
Display of the maximum phase-to-ground voltage referred to V
nom
.
MAIN: Voltage VPG,min p.u.
009 043
Fig. 3-33
Display of the minimum phase-to-ground voltage referred to V
nom
.
MAIN: Voltage A-G p.u.
005 043
Fig. 3-33
Display of the updated value for phase-to-ground voltage A-G referred to
V
nom
.
MAIN: Voltage B-G p.u.
006 043
Fig. 3-33
Display of the updated value for phase-to-ground voltage B-G referred to
V
nom
.
MAIN: Voltage C-G p.u.
007 043
Fig. 3-33
Display of the updated value for phase-to-ground voltage C-G referred to
V
nom
.
MAIN: Volt. Σ(VPG)/©3 p.u.
005 013
Fig. 3-33
Display of the calculated neutral-displacement voltage referred to V
nom
.
